Camera
|
|
Image Sensor
|
1/2.7 inch CMOS
|
|
Effective Pixels
|
3840 (H)× 2160 (V), 4K
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s
|
|
S/N Ratio
|
>65dB
|
|
Minimum Illumination
|
0.03Lux/F2.0, 30IRE, 0Lux IR on
|
|
Fill Light Working Distance
|
20 m (65.2 ft)
|
|
IR On/Off Control
|
Auto; manual
|
|
IR LED Number
|
12
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Mount Type
|
M12
|
|
Focal Length
|
2.8 mm; 3.6 mm
|
|
Max. Aperture
|
F2.0
|
|
Angle of View
|
2.8mm: 125° x 105° x 56° (diagonal x horizontal x vertical)
3.6mm: 104° x 87° x 47° (diagonal x horizontal x vertical)
|
|
Iris Type
|
Fixed iris
|
|
Close Focus Distance
|
2.8mm: 1.0 m (3.3 ft)
3.6mm: 1.8 m (6.2 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8mm
|
74.7 m (245.1 ft)
|
29.9 m (98.1 ft)
|
14.9 m (48.9ft)
|
7.5 m
(24.6 ft)
|
|
3.6mm
|
106.7 m (350.1 ft)
|
42.7 m (140.1 ft)
|
21.3 m (69.9 ft)
|
10.7 m (35.1 ft)
|
|
Video
|
|
Frame Rate
|
CVI: 4K@25/30fps; 4K@15fps; 5M@20fps;
4M@25fps/30fps;
AHD: 4K@15fps;
TVI: 4K@15fps;
CVBS: 960H
|
|
Resolution
|
4K (3840 × 2160); 5M (2592 × 1944); 4M (2560 × 1440); 960H (960 × 576/960 × 480)
|
|
Day/Night
|
Auto switch by ICR
|
|
BLC
|
BLC/HLC/WDR
|
|
WDR
|
DWDR
|
|
White Balance
|
Auto; manual
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
2D NR
|
|
Smart IR
|
Yes
|
|
Mirror
|
Off/On
|
|
Privacy Masking
|
Off/On (8 area, rectangle)
|
|
Certifications
|
|
Certifications
|
CE (EN55032, EN55024, EN50130-4,EN60950-1)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
|
|
Port
|
|
Video Output
|
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
|
|
Power
|
|
Power Supply
|
12V ±30% DC
|
|
Power Consumption
|
Max 3.56W (12V DC, IR on)
|
|
Environment
|
|
Operating Temperature
|
-40°C to +55°C (-40°F to +131°F);
<95% (non-condensation)
|
|
Storage Temperature
|
-40°C to +55°C (-40°F to +131°F);
<95% (non-condensation)
|
|
Protection Grade
|
IP50
|
|
Structure
|
|
Casing
|
Plastic
|
|
Camera Dimensions
|
φ85.4 mm × 70.2 mm (φ3.36" × 2.76")
|
|
Net Weight
|
0.12 Kg (0.26 lb)
|
|
Gross Weight
|
0.19 kg (0.42 lb)
|
