Punto de acceso Wi-Fi 7 de montaje en techo BE9300
-
Velocidad Ultrarrápida Wi-Fi 7. Hasta 5760Mbps en 6GHz, 2880Mbps en 5GHz y 574 Mbps en 2,4GHz para alcanzar un total de 9.300Mbps†.
-
Puerto Ethernet 2,5G. Aumenta el rendimiento total de la red con el acceso por cable adaptativo a 2,5G y Gigabit.
-
Triple banda. Añade la banda de 6GHz a las de 5GHz y 2,4GHz para enviar datos con mayor estabilidad y velocidad.
-
Ancho de banda de 320MHz. Conecta más dispositivos a la vez con un alto rendimiento y máxima velocidad.
-
Menos interferencias y baja latencia. Con las tecnologías Multi-Link Operation y Multi-RU se garantiza el uso de las 3 bandas simultáneamente con alto rendimiento.‡
-
Gestión Centralizada. Con la controladora Omada se obtiene un control intuitivo y eficiente de la red con acceso en local o desde la nube.
-
Wi-Fi Mesh Inteligente. Tecnología Wi-Fi Mesh con Roaming inteligente por IA
| CARACTERÍSTICAS DE HARDWARE |
| Interfaz |
1× 2.5G Ethernet Port |
| Botones |
Reset |
| Fuente de Alimentación |
802.3at PoE or 12V/2.5A DC |
| Consumo de Potencia |
• 24.05 W (For PoE); • 20.92 W (For DC) |
| Dimensiones |
8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm) |
| Antenas |
• 2.4 GHz: 2× 4.0 dBi • 5 GHz: 2× 5.0 dBi • 6 GHz: 2× 5.0 dBi |
| Bluetooth |
1 × 4.0 dBi, Bluetooth 5.2 *Firmware update may be required. |
| Montaje |
Ceiling / Wall Mounting (Kits Included) |
| CARACTERÍSTICAS INALÁMBRICAS |
| Coverage |
140㎡(1500 ft²)§
|
| Clientes concurrentes |
380+**
|
| Estándares Inalámbricos |
IEEE 802.11 a/b/g/n/ac/ax/be |
| Frecuencia |
6 GHz, 5 GHz, and 2.4 GHz |
| Tasa de Señal |
574 Mbps (2.4 GHz) + 2880 Mbps (5 GHz) + 5760 Mbps (6 GHz)†
|
| Funciones Inalámbricas |
• MLO‡ • 4K-QAM‡ • Seamless Roaming(802.11k/v/r) • MU-MIMO‡ • EHT320‡ • Mesh△ • BSS Coloring‡ • OFDMA‡ • Load Balance • Band Steering • Beamforming • Airtime Fairness • Multiple SSIDS:24(8 on each band) • Wireless Schedule • Reboot Schedule • QoS(WMM) • Rate Limit • Static IP/Dynamic IP • RADIUS Accounting • MAC Authentication |
| Seguridad Inalámbrica |
• Captive Portal Authentication△ • Access Control • Maximum number of MAC Filter: 4,000 • Wireless Isolation Between Clients • VLAN • Rogue AP Detection • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Potencia de Transmisión |
< 20 dBm (2.4 GHz, EIRP) < 23 dBm (5 GHz, band 1&band 2, EIRP) < 28 dBm (5 GHz, band 3, EIRP) < 23dBm (6 GHz, EIRP)
|
| GESTIÓN |
| Omada App |
Yes |
| Gestión Centralizada |
• Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller
|
| Acceso a la nube |
Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller. |
| Alertas por Correo Electrónico |
Yes |
| LED de control ON / OFF |
Yes |
| Control de Gestión de Acceso MAC |
Yes |
| SNMP |
v1, v2c, v3 |
| Acceso al Registro de Sistema Local/ Registro del Sistema Remoto |
Yes |
| Gestión basada en Web |
Yes |
| Otros |
| Certificaciones |
CE, FCC, RoHS, IC |
| Contenido del Paquete |
• EAP772 • Installation Guide • Ceiling/Wall Mounting Kit Note: Power Adapter is NOT included. |
| Factores Ambientales |
• Operating Temperature: 0 °C–40 °C (32 °F–104 °F); • Storage Temperature: -40 °C–70 °C (-40 °F–158 °F); • Operating Humidity: 10%–90% non-condensing; • Storage Humidity: 5%–90% non-condensing; |
