| Model |
NSW2020-16T1GT1GC-POE-INM |
| Ports |
16×10/100Mbps PoE+ ports (RJ45)+2×1000Mbps Combo ports,RJ45 port, full duplex, MDI/MDI-X adaptive |
| Standards |
IEEE802.3,IEEE802.3u,IEEE802.3z,IEEE802.3ab,IEEE802.3x,IEEE802.3af,IEEE802.3at,IEEE802.3az |
| Ports for long-distance transmission |
Ports 1 to 16 |
| Switching capacity |
7.2Gbps |
| Forwarding performance |
5.36Mpps |
| Forwarding mode |
Store-and-forward switching |
| Packet Buffer |
4M bit |
| MAC |
16K |
| Dimensions (W×D×H) |
440*189.8*44mm |
| Weight |
2.12KG |
| Power supply |
AC: 100-240V, 50/60Hz, Max. 2.5A |
| PoE |
802.3at/af （4/5+，7/8-） |
| Max. PoE Power |
Max capacity: 225W
Max capacity for single port: 30W |
| Switch Power/ Consumation |
Max. 150W |
| Prior Ports |
1~8 |
| Cooling Fans |
1 |
| Operating temperature |
-10°C-55°C (14°F-131°F) |
| Operating humidity |
10%～90% (noncondensing) |
| Storage humidity |
5%～90% (noncondensing) |
| Indicator |
POWER:
Steady on: AC input is normal
Off: No AC input |
PoE:
Off: No PoE power supply
Steady on: PoE power supply is normal |
PoE-MAX：
off ：The POE power supply power of the whole machine is less than 80% of the specification
Steady on : The POE power supply power of the whole machine is greater than 85% of the specification |
LINK/ACT：
Off: No link
Steady on: Linked
Flashing: Transmitting data |
| Working Mode |
Default(Normal mode) : All ports can communicate with each other.
VLAN(Secure mode): Downlink ports can communicate only with uplink ports. Enabling PD keepalive function, the switch will restart the IPC via PoE power when the IPC sends no message in a period of time.
Extend(Surveillance mode): Transmission distance up to 250 meters. Downlink ports can communicate only with uplink ports. |
| Certifications |
CE: CE-LVD (EN 62368-1:2014/A11:2017）; CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013);
CE-EMC (EN 55032: 2015;EN 55035:2017;
EN 61000-3-2:2014;EN 61000-3-3:2013+A1:2019); CE-RoHS (2011/65/EU;(EU)2015/863 );
RCM (AS/NZS CISPR 32: 2015); 1C (ICES-003: Issue 6, 2016)
UL: UL (UL 62368-1)
FCC: FCC (47 CFR Part 15, Subpart B);
KC: KC (KN 32: 2015, KN 35: 2015)
WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
